TNAP-6 Image Discussion

[el bandido]

I think you are missing a piece of the puzzle. The path has to be exactly this: /media/usb/ServiceScan
Or exact path: /media/FTA/ServiceScan
Or exact path: /hdd/ServiceScan
If none of those paths can be found, then the reports are dumped into /tmp, and there is no folder provision for /tmp
Also understand the /tmp folder is dumped during a reboot and that is why I call it the temporary folder!

It has been like this for years. Normally when you stick an usb drive into the receiver, you automatically get: /media/usb
And the name of the Folder has to be exactly ServiceScan
Here is what one of my receiver's looks like:

root@sf8008:~# ls -lh /media/usb/ServiceScan/
-rw-r--r--    1 root     root        1.3K Sep 21 21:13 100.9W_Ku-band_113ch_1tp_09-21-2025_21-13-52.xml
-rw-r--r--    1 root     root        1.4K Oct  2 00:24 100.9W_Ku-band_114ch_1tp_10-02-2025_00-24-55.xml
-rw-r--r--    1 root     root        1.4K Oct  2 00:26 100.9W_Ku-band_114ch_1tp_10-02-2025_00-26-01.xml
-rw-r--r--    1 root     root        1.3K Sep 20 15:38 100.9W_Ku-band_11ch_1tp_09-20-2025_15-38-25.xml
-rw-r--r--    1 root     root        1.3K Sep 21 07:50 100.9W_Ku-band_17ch_1tp_09-21-2025_07-50-29.xml
-rw-r--r--    1 root     root        1.3K Sep 21 07:51 100.9W_Ku-band_17ch_1tp_09-21-2025_07-51-49.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:32 101.0W_Ku-band_113ch_1tp_09-20-2025_21-32-09.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:33 101.0W_Ku-band_113ch_1tp_09-20-2025_21-33-30.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:35 101.0W_Ku-band_113ch_1tp_09-20-2025_21-35-47.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:41 101.0W_Ku-band_113ch_1tp_09-20-2025_21-41-28.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:51 101.0W_Ku-band_113ch_1tp_09-20-2025_21-51-27.xml
-rw-r--r--    1 root     root        1.3K Sep 20 22:27 101.0W_Ku-band_113ch_1tp_09-20-2025_22-27-22.xml
-rw-r--r--    1 root     root        1.3K Sep 20 22:30 101.0W_Ku-band_113ch_1tp_09-20-2025_22-30-43.xml
-rw-r--r--    1 root     root        1.3K Sep 21 21:14 101.0W_Ku-band_113ch_1tp_09-21-2025_21-14-35.xml
-rw-r--r--    1 root     root        1.3K Oct 28 09:07 101.0W_Ku-band_114ch_1tp_10-28-2025_09-07-08.xml
-rw-r--r--    1 root     root        1.3K Sep 20 15:39 101.0W_Ku-band_11ch_1tp_09-20-2025_15-39-59.xml
-rw-r--r--    1 root     root        1.3K Sep 20 19:20 101.0W_Ku-band_11ch_1tp_09-20-2025_19-20-11.xml
-rw-r--r--    1 root     root        1.3K Sep 20 20:21 101.0W_Ku-band_11ch_1tp_09-20-2025_20-21-41.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:00 101.0W_Ku-band_11ch_1tp_09-20-2025_21-00-27.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:05 101.0W_Ku-band_11ch_1tp_09-20-2025_21-05-43.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:09 101.0W_Ku-band_11ch_1tp_09-20-2025_21-09-03.xml
-rw-r--r--    1 root     root        1.3K Sep 20 21:37 101.0W_Ku-band_11ch_1tp_09-20-2025_21-37-25.xml
-rw-r--r--    1 root     root       16.4K Sep 20 20:42 101.0W_Ku-band_166ch_16tp_09-20-2025_20-42-15.xml
-rw-r--r--    1 root     root       16.5K Sep 21 00:20 101.0W_Ku-band_168ch_16tp_09-21-2025_00-20-13.xml
-rw-r--r--    1 root     root       16.6K Oct 28 08:21 101.0W_Ku-band_168ch_16tp_10-28-2025_08-21-59.xml
-rw-r--r--    1 root     root        1.3K Sep 20 23:06 101.0W_Ku-band_17ch_1tp_09-20-2025_23-06-45.xml
-rw-r--r--    1 root     root        1.3K Sep 20 23:10 101.0W_Ku-band_17ch_1tp_09-20-2025_23-10-08.xml
-rw-r--r--    1 root     root        1.3K Sep 20 23:32 101.0W_Ku-band_17ch_1tp_09-20-2025_23-32-53.xml
-rw-r--r--    1 root     root        1.3K Sep 20 23:38 101.0W_Ku-band_17ch_1tp_09-20-2025_23-38-48.xml
-rw-r--r--    1 root     root        1.3K Sep 21 00:07 101.0W_Ku-band_17ch_1tp_09-21-2025_00-07-55.xml
-rw-r--r--    1 root     root        1.3K Sep 21 06:43 101.0W_Ku-band_17ch_1tp_09-21-2025_06-43-21.xml
-rw-r--r--    1 root     root        1.3K Sep 21 07:52 101.0W_Ku-band_17ch_1tp_09-21-2025_07-52-39.xml
-rw-r--r--    1 root     root        1.3K Sep 21 20:51 101.0W_Ku-band_17ch_1tp_09-21-2025_20-51-03.xml
-rw-r--r--    1 root     root        1.6K Sep 21 19:33 101.1W_C-band_16ch_1tp_09-21-2025_19-33-04.xml
-rw-r--r--    1 root     root        1.6K Sep 30 21:51 101.1W_C-band_16ch_1tp_09-30-2025_21-51-29.xml
-rw-r--r--    1 root     root      191.2K Oct  8 02:05 105.1W_C-band_2097ch_18tp_10-08-2025_02-05-01.xml
-rw-r--r--    1 root     root        2.3K Oct 30 11:42 105.1W_C-band_24ch_1tp_10-30-2025_11-42-42.xml
drwxrwxr-x    2 root     root        4.0K Apr 23  2025 105w-pid-test
-rw-r--r--    1 root     root       24.3K Sep 29 00:03 117.0W_Ku-band_296ch_30tp_09-29-2025_00-03-01.xml
-rw-r--r--    1 root     root        5.6K Oct 26 08:33 127.1W_C-band_63ch_7tp_10-26-2025_08-33-59.xml
-rw-r--r--    1 root     root        9.3K Oct 25 11:55 133.1W_C-band_113ch_9tp_10-25-2025_11-55-54.xml
-rw-r--r--    1 root     root        3.0K Oct 20 10:37 87.1W_Ku-band_11ch_12tp_10-20-2025_10-37-31.xml
-rw-r--r--    1 root     root        3.2K Oct 18 13:20 87.1W_Ku-band_13ch_13tp_10-18-2025_13-20-09.xml
-rw-r--r--    1 root     root        3.6K Oct 20 11:02 87.1W_Ku-band_19ch_13tp_10-20-2025_11-02-07.xml
-rw-r--r--    1 root     root        3.7K Oct 23 12:36 87.1W_Ku-band_20ch_14tp_10-23-2025_12-36-10.xml
-rw-r--r--    1 root     root        2.0K Oct 28 19:45 87.1W_Ku-band_4ch_9tp_10-28-2025_18-45-39.xml
-rw-r--r--    1 root     root         735 Oct 17 20:20 89.1W_C-band_1ch_1tp_10-17-2025_20-20-33.xml
-rw-r--r--    1 root     root         734 Oct 19 11:03 89.1W_C-band_1ch_1tp_10-19-2025_11-03-36.xml
-rw-r--r--    1 root     root        1.5K Oct 14 17:04 89.1W_C-band_2ch_6tp_10-14-2025_17-04-30.xml
-rw-r--r--    1 root     root        1.7K Nov  6 20:49 89.1W_C-band_4ch_7tp_11-06-2025_20-49-06.xml
-rw-r--r--    1 root     root        1.7K Oct 17 20:19 89.1W_C-band_5ch_6tp_10-17-2025_20-19-14.xml
-rw-r--r--    1 root     root        1.7K Oct 17 20:24 89.1W_C-band_5ch_6tp_10-17-2025_20-24-53.xml
-rw-r--r--    1 root     root        1.7K Oct 25 09:28 89.1W_C-band_8ch_4tp_10-25-2025_09-28-22.xml
-rw-r--r--    1 root     root         512 Oct 19 13:55 91.0W_Ku-band_Scan-Report_19-10-2025_13-55-55
-rw-r--r--    1 root     root       14.5K Nov  8 11:32 97.1W_C-band_160ch_11tp_11-08-2025_11-32-03.xml
-rw-r--r--    1 root     root       11.4K Sep 26 00:04 99.2W_Ku-band_107ch_18tp_09-26-2025_00-04-10.xml
drwxrwxr-x    2 root     root       26.9M Sep 20 00:54 Archive
drwxr-xr-x    2 root     root        4.0K Apr 24  2024 Factory Driver Test
drwxr-xr-x    4 root     root        4.0K Apr 22  2024 OpenATV
drwxr-xr-x    4 root     root        4.0K Apr 22  2024 OpenVix
-rw-r--r--    1 root     root        7.9K Oct 25 20:16 _ATSC_51ch_35tp_10-25-2025_20-16-08.xml
-rw-r--r--    1 root     root        8.2K Nov  3 12:08 _ATSC_57ch_35tp_11-03-2025_11-08-38.xml
-rw-r--r--    1 root     root        8.3K Sep 21 21:43 _ATSC_58ch_35tp_09-21-2025_21-43-00.xml
-rw-r--r--    1 root     root         985 Sep 20 01:43 _ATSC_6ch_1tp_09-20-2025_01-43-24.xml
-rw-r--r--    1 root     root         987 Oct 20 00:28 _ATSC_6ch_1tp_10-19-2025_23-28-43.xml
drwxrwxr-x    2 root     root        4.0K Apr 22  2024 sf8008-Supreme
root@sf8008:~#



[cyberham]

... Just change line 255 and 256 in the attached file.

Original lines:

                        if os.path.exists("/media/usb/ServiceScan"):
                            self.xml_dir = "/media/usb/ServiceScan"

As an example, change to:

                        if os.path.exists("/media/MASTER/ServiceScan"):
                            self.xml_dir = "/media/MASTER/ServiceScan"

Got it working! I edited 'usb' to 'MASTER'. The reports are now writing into ServiceScan in MASTER. And I can use Dream-Explorer plugin to review the scans using just my remote as I used to do. Very convenient.



[cyberham]

I'm curious why the SNR values are all wrong in the ServiceScan reports? For example, attached shows SNR=2.13 or 2.18. But the transponder was actually SNR 9.7 dB as reported by Signal Finder.



[cyberham]

...I use backupsuite and have no problems with it using /media/usb for a backup path...

The backup completed this morning. It reported taking 33.35 minutes. I probably never waited long enough before.



[el bandido]

I'm curious why the SNR values are all wrong in the ServiceScan reports? For example, attached shows SNR=2.13 or 2.18. But the transponder was actually SNR 9.7 dB as reported by Signal Finder.

Each of the various drivers for Edision output a different value that has to be calibrated. This has been done before, then an addition or upgrade causes problems. Put in a simple way, time is needed to sort this. At least it can be fixed.

The backup completed this morning. It reported taking 33.35 minutes. I probably never waited long enough before.

The Backupsuite works. It is that simple. What Backupsuite does is not very complex, but to make it work correctly took a very talented individual. I would allow that it is possible where Backupsuite would work on one receiver and not another due to a coding issue, but that is not very likely.

Two things will greatly influence Backupsuite.
(1) Device that will be written to. Cheap usb drives are usually junk. Old drives may not work the same way they used to work. Make sure you have at least a decent quality drive for Backupsuite to use as there are thousands of files that have to be copied. A slow or compromised drive will add considerable time, may cause the process to fail, or even cause a No Boot situation when being reinstalled in the receiver. Junk In = Junk Out!
(2) Files that are being backed up. In general people are lazy and will use auto restore repeatedly when loading new images. Or they will simply have a lot of things installed that causes bloat. Backupsuite shows the size of file to be backed up and also shows other information that few users ever look at.

The Bottom Line here is what is being backed up as compared to what it is being backed up ON. If you have a bunch of junk to backup and are using a compromised drive to write the junk to, then the backup process will run for a long time. It's that simple.

Here is a backup starting on my OSMIo4k today:


And here is the backup completed some minutes later:


I do not have a thousand dollar usb drive, but it is working correctly. Check the two things mentioned above and study the screenshot examples. Let me know if you continue to have backup problems and we will look at more in depth. But it stands to reason if it works for me, it should work for you.



[cyberham]

Each of the various drivers for Edision output a different value that has to be calibrated. This has been done before, then an addition or upgrade causes problems. Put in a simple way, time is needed to sort this. At least it can be fixed.

For comparison, I did blind scans using the No T2MI (my favourite), the T2MI and the T2MI Low SR drivers. The No T2MI driver showed a low reading as shown in my last message, and the T2MI and T2MI Low SR drivers showed very high readings around 60 dB. So I'll stick with my favourite for now since it's the fastest and most accurate in my experience.

The Backupsuite works...

I am using a USB memory stick (SanDisk 3.2Gen1 w/113GB free) only temporarily until I decide on and order an external USB drive. It's for backup and to timeshift programs which I erase after watching. The first drive ordered was damaged in transit, returned and could not be replaced by the seller. So I'm back to square one. I won't be doing more backups until I get my permanent drive. I just wanted to have something as a backup in the interim.



[el bandido]

IMO, you need to see what you are backing up. Backupsuite shows this at the start. If you are trying to backup 600-800 MB then find out WHY. I think my backups are usually less than 500MB. This is something to look at. A drive is a moot point if you are backing up garbage. That should be a very capable backup drive you have, and it is also possible the usb port on the receiver is causing a bottleneck. Maybe try a different usb port.
